T5 4FT

Categories ,

The T5 was designed as the best solution to replace traditional fluorescent fixtures. It gives off consistent bright light. Having a dynamic purpose, the Big Shine LED tube is helpful in commercial, public and industrial settings. This LED tube’s single end power anti-electric shock ensures safety. Its internal driver provides convenience for every installation. The tubes are easy to put in and require no maintenance. Patented with a 180° rotating end cap, this design allows for the best lighting results.

These tubes have a diameter equal to 5 times an eighth of an inch, or 5/8″. They are about 40% smaller than T8 lamps, which are one inch in diameter, and almost 60% smaller than T12 lamps, which are 1½” in diameter.

Specifications

Application

Regulatory & Voluntary Qulifications

  • ETL certified
  • Light Source Engine : LED
  • Driver/Power Unit/Transformer Power Supply Unit Regulating with constant light output
  • Not intended for use in environments containing airborne corrosive agents
  • TM21 results are available upon request

Special Features

Base Type: G13, R1, D7FA8, G16T-5, Rotable Tubes

Field Beam Angles

MODEL

Beam

Beam Angle

9.8 ft

19.7 ft

29.5 ft

BSL-TL18-TBU-BSES-5000K-160

160

160

60.9

15.2

6.8

Technical Specifications

18W

Lumens

2160

Efficacy

120

CRI

80 (5000K)

Voltage Input

100-277V

Voltage Output

36V

Amperage

1

Hertz

50-60 Hz

Total Harmonic Dist.

<25%

Control Options

Non-Dimmable

Operating Temp.

-4~104°F

IP Rating

IP20

IK Level

N/A

Weight

1 lb

Driver Life

50000 hrs

1 LM80 and TM21 results are available upon request.

Specifications are subject to change without notice.

Downloads

Spec Sheets

Specification Sheet   DOWNLOAD

IES Files

BSL-TB15-T54-4000K-140-C-T (120V) DOWNLOAD
BSL-TB15-T54-4000K-140-C-T (277V) DOWNLOAD
BSL-TB18-T54-4000K-120-F-T DOWNLOAD
BSL-TB18-T54-5000K-120-F-T DOWNLOAD
BSL-TB24-T54-5000K-120-F-TDOWNLOAD
BSL-TB24-T54-5000K-140-C-TDOWNLOAD

DLC Reports

BSL-TB15-T54-3100KDOWNLOAD
BSL-TB15-T54-4500KDOWNLOAD
BSL-TB15-T54-5000KDOWNLOAD



BSL-TB18-T54-2700KDOWNLOAD
BSL-TB18-T54-3000KDOWNLOAD
BSL-TB18-T54-3100KDOWNLOAD
BSL-TB18-T54-3500KDOWNLOAD
BSL-TB18-T54-4500KDOWNLOAD
BSL-TB18-T54-5000KDOWNLOAD
BSL-TB24-T54-2700KDOWNLOAD
BSL-TB24-T54-4500KDOWNLOAD
BSL-TB24-T54-5000KDOWNLOAD
BSL-TB24-T54-6000KDOWNLOAD
BSL-TB24-T54-6500KDOWNLOAD


Photometric Layouts

*Foot candles vary

Additional information

Beam Angle

18°, 190°, 210°

CRI

90

CCT

2500K-3500K

Efficacy

110 lm/w
