U-Shape

Categories ,

The Big Shine LED U-Shape tube is an ideal replacement for traditional fluorescent fixtures. Unlike fluorescent lights, Big Shine LED tubes are built to withstand impact as well as vibration. Fluorescents are sensitive to vibration. Becoming worn down quickly over time through exterior settings. LED tube lighting allows for a mercury free, safe environment. Although florescent lighting consumes low amounts of energy, LED lighting is significantly more efficient as well as ec0-friendly. Additionally, Big Shine LED tube lights are also integrated with an Epistar chip which gives off consistent bright light for up to 50,000 hours.

Specifications

Application

Regulatory & Voluntary Qulifications

  • ETL certified
  • Light Source Engine : LED
  • Driver/Power Unit/Transformer Power Supply Unit Regulating with constant light output
  • Not intended for use in environments containing airborne corrosive agents
  • TM21 results are available upon request

Special Features

Base Type: G13, R1, D7FA8, G16T-5, Rotable Tubes

Field Beam Angles

MODEL

Beam

Beam Angle

9.8 ft

19.7 ft

29.5 ft

BSL-TL18-TBU-BSES-5000K-160

160

160

60.9

15.2

6.8

Technical Specifications

18W

Lumens

2160

Efficacy

120

CRI

80 (5000K)

Voltage Input

100-277V

Voltage Output

36V

Amperage

1

Hertz

50-60 Hz

Total Harmonic Dist.

<25%

Control Options

Non-Dimmable

Operating Temp.

-4~104°F

IP Rating

IP20

IK Level

N/A

Weight

1 lb

Driver Life

50000 hrs

1 LM80 and TM21 results are available upon request.

Specifications are subject to change without notice.

Downloads

Spec Sheets

18W Spec Sheet Download

IES Files

BSL-TL18-T8U-GNES-5000K-160 Download

Photometric Layouts

Additional information

Beam Angle

18°, 190°, 210°

CRI

90

CCT

2500K-3500K

Efficacy

110 lm/w
